INCH-POUND
MIL-DTL-27434/9A
30 October 2008
SUPERSEDING
MIL-A-27434/9
28 September 1960
DETAIL SPECIFICATION SHEET
ADAPTER, CONNECTOR, COAXIAL, RADIOFREQUENCY,
BETWEEN SERIES, SERIES LC, SOCKET CONTACT, TO SERIES N, SOCKET CONTACT,
TYPE UG270A/U
INACTIVE FOR NEW DESIGN
AFTER 19 FEBRUARY 1982
This specification is approved for use by all Departments
and Agencies of the Department of Defense
The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-DTL-27434.
Inch
(mm)
2.20
5.59
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 1. Type UG 270A/U connector adapter.
AMSC N/A
FSC 5935
