INCH-POUND
MIL-DTL-12520/8B
31 March 2005
SUPERSEDING
MIL-C-12520/8A (EL)
5 November 1965
DETAIL SPECIFICATION SHEET
CONNECTORS, RECEPTACLE, ELECTRICAL WATERPROOF
(SHELL SIZE 20, MALE INSERTS)
Inactive for new design after 24 June 1999.
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-12520.
FIGURE 1. Receptacle shell and insert dimensions.
AMSC N/A
FSC 5935
