MIL-DTL-12883/11E
TABLE I. Dash number and characteristics.
Dash
Operating temperature
Insulating material
Old type
number
ºC
designator 1/
-01
200
Ceramic
TS103C03 (2-way)
-02
100
SDG-F, GDI-30F
TS103P03 (1-way)
-03
200
MFE
TS103P03 (2-way)
1/ 1-way replacement: The new item (designated by military part number) will
replace the old item (formerly designated by type designator); however, the old
item will not replace the new item.
2-way replacement: The new items are interchangeable; i.e., the new item will
replace the old item, and the old item will replace the new item.
Ratings (absolute maximum):
Voltage:
Sea level: 500 volts rms.
50,000 feet (15.24 km): 225 volts rms.
Current: 1 ampere.
Operating temperature: See table I.
Test gage details: See table II and MIL-DTL-12883 (see appendix).
