MIL-DTL-12883/49B
Inches
mm
Inches
mm
Inches
mm
12.7
.50
1.5
.06
0.03
.001
16.43
.647
1.57
.062
0.08
.003
19.84
.781
2.36
.093
0.13
.005
27.76
1.093
5.10
.201
0.15
.006
30.73
1.210
5.36
.211
0.25
.010
33.27
1.31
6.36
.250
0.38
.015
34.11
1.343
7.9
.31
0.76
.030
36.20
1.425
9.09
.358
0.8
.03
39.67
1.562
11.56
.455
1.04
.041
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is + .010 inch (0.25 mm).
4. Material shall be annealed stainless steel in accordance with SAE-AMS-QQ-S-763, type 302 or
304L.
FIGURE 1. Outline configurations Continued.
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Material: 302 stainless steel, annealed and nickel plated in accordance with SAE-AMS-QQ-N-290, 100
microinches minimum, or 304L stainless steel, annealed and passivated.
Finish: Shot peen, in accordance with AMS-S-13165.
Plating: Sulfamate nickel in accordance with SAE-AMS-QQ-N-290. Thickness shall be 100 microinches
(2.54µm) minimum.
Part or Identifying Number (PIN): The PIN shall consist of the basic number of this specification sheet
and the dash number from table I.
Example:
M12883/49
-001
Basic document number
Dash number (see table I)
