MIL-DTL-12883/51B
Inches
mm
Inches
mm
Inches
mm
Inches
mm
5.41
.213
1.57
.062
0.76
.030
.001
0.03
7.92
.312
1.75
.069
0.81
.032
0.05
.002
20.32
.800
2.54
.100
1.04
.041
0.08
.003
20.63
.812
4.34
.171
1.19
.047
0.13
.005
25.54
1.006
4.55
.179
1.52
.060
0.41
.016
33.15
1.305
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ± .010 inch (0.25 mm).
4. Terminal markings shall be of a contrasting color to the socket surface and shall appear on both the
bottom and top surface per the applicable specification.
5. Color code, top surface of socket in accordance with table I.
FIGURE 1. Dimensions and configurations Continued.
REQUIREMENTS:
Dimensions and configurations: See figure 1 and table I.
TABLE I. Dimensions. 1/ 2/ 3/
Configuration
A
B
C
D
Max
Max
Max
Max
I
2.520 (64.01)
1.540 (39.12)
1.005 (25.53)
1.326 (33.68)
II
2.520 (64.01)
1.540 (39.12)
1.005 (25.53)
1.326 (33.68)
III
3.320 (84.33)
2.340 (59.44)
1.020 (25.91)
2.123 (53.92)
IV
3.320 (84.33)
2.340 (59.44)
1.020 (25.91)
2.123 (53.92)
V
3.320 (84.33)
2.340 (59.44)
1.020 (25.91)
2.123 (53.92)
VI
2.520 (64.01)
1.540 (39.12)
1.005 (25.53)
1.326 (33.68)
1/ Dimensions are in inches.
2/ Metric equivalents are given for general information only.
3/ Metric equivalents are in parenthesis.
Material:
Body: Polyetherimide.
Bracket: 17-7 ph cres passivated in accordance with SAE AMS QQ-P-35.
Plating: Sulfamate nickel in accordance with SAE-AMS-QQ-N-290, 100 microinches minimum.
Grommet: Silicone rubber.
3
