MIL-DTL-12883/53B
Application data:
With relays mated to sockets attached to the mounting track assembly, the assembly shall meet
the applicable mechanical, environmental, and electrical requirements of the applicable relay
specifications.
Use tool M6106/32-001 to remove M1288/52 sockets.
Use tool M6106/31-001 to remove relays from this mounting bracket.
Part of Identifying Number (PIN): The PIN shall be marked on the mounting track as shown in the
example (see figure 1). The PIN shall consist of the basic number of this specification sheet and the dash
number.
Example:
-001
M12883/53
Basic document number
Dash number
Supersession data: See table I.
TABLE I. Supersession data. 1/
Superseded dash number
Superseding
M6106/25-
PIN
001
M12883/51-001
002
M12883/51-002
003
M12883/51-003
1/ For Government logistics support, supersession data becomes
applicable when a qualified products list becomes available.
The Government PIN, specified in table II, supersedes the following commercial PINs.
TABLE II. Supersession and cross reference.
Superseded
Active
manufacturers
Government
PIN
PIN
CAGE
58982
M12883/53-001
RST145005
3
