MIL-DTL-21097/3F
TABLE I. Connector, electrical, composite, adapter, type CS, class b, no mounting provision.
Dimensions (inches) 1/ 2/
A
B
C
±0.005
±0.010
Dash
(maximum)
number
Style
Size
(0.13)
(0.25)
01
12
2
2.620
2.200
.122
(66.55)
(55.88)
(3.10)
02
12
3
2.620
2.200
.153
(66.55)
(55.88)
(3.89)
03
15
2
3.220
2.800
.122
(81.79)
(71.12)
(3.10)
04
15
3
3.220
2.800
.153
(81.79)
(71.12)
(3.89)
05
18
2
3.820
3.400
.122
(97.03)
(86.36)
(3.10)
06
18
3
3.820
3.400
.153
(97.03)
(86.36)
(3.89)
07
22
2
4.620
4.200
.122
(117.35)
(106.68)
(3.10)
08
22
3
4.620
4.200
.153
(117.35)
(106.68)
(3.89)
09
26
2
5.420
5.000
.122
(137.67)
(127.0)
(3.10)
10
26
3
5.420
5.000
.153
(137.67)
(127.0)
(3.89)
1/. Dimensions are in inches.
2/. Metric equivalents are given for information only.
REQUIREMENTS
Dimensions and configurations: See figure 1, figure 2, and table I.
Polarizing keys: Part or Identifying Number (PIN) M21097/11-03 or M21097/11-04. A key is inserted
into the card slot at even contact numbers 2, 4, 6, etc.
Mating receptacles: Shall be in accordance with MIL-DTL-21097/2.
Printed wiring test boards: Shall be in accordance with IPC-D-275 and MIL-PRF-31032.
Finish: Gold plating in accordance with ASTM B488, type II, code C, class 1.27, over nickel plating in
accordance with SAE-AMS-QQ-N-290, class 2, 30 to 150 microinches.
Retention of qualification: Group A inspection only.
PIN: M21097/3-(dash number from table I).
