MIL-DTL-21097/4G
Inches
mm
Inches
mm
.001
.03
.098
2.49
.002
.05
.100
2.54
.004
.10
.116
2.95
.005
.13
.125
3.18
.015
.38
.128
3.25
.020
.51
.140
3.56
.026
.66
.150
3.81
.030
.76
.200
5.08
.040
1.02
.210
5.33
.044
1.12
.325
8.26
.046
1.17
.326
8.28
.050
1.27
.328
8.33
.079
2.01
.350
8.89
Board guide
A dim
+ .002 (.05)
- .004 (.10)
.06 (1.52)
.119 (3.02)
.09 (2.29)
.150 (3.81)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only .
3. Unless otherwise specified, tolerance is ± .010 (.25 mm) for three place decimals.
4. Contacts and terminals shall be designated on the connector using numerals in the locations
shown.
5. The shape of the barriers is optional except that barriers shall not protrude beyond the plane of the
underside of the mounting flange.
6. Slot shall accept the following thickness printed wiring boards:
Size 2 - .054 (1.37 mm) to .071 (1.80 mm)
Size 3 - .086 (2.18 mm) to .103 (2.62 mm)
Slot shall prevent entry of printed wiring board having the following thickness:
Size 2 - .084 (2.13 mm)
Size 3 - .113 (2.87 mm)
FIGURE 1. Dual row contacts, type CR Continued.
2
