MIL-DTL-21617B
TABLE X. Group B inspection.
Inspection
Requirement
Test
Sampling plan
paragraph
paragraph
Contact resistance
See table XI
Insulation resistance
Dielectric withstanding voltage
4.4.2.2.1 Sampling plan for group B. The sampling plan for group B shall be in accordance with table
XI.
TABLE XI. Sampling plan for group B inspection.
Lot size
Sample size
Sample size
(tightened
inspection)
2 to
8
All
All
9 to
15
13
All
16 to
25
13
20
26 to
50
13
20
51 to
90
13
20
91 to 150
13
20
151 to 280
20
20
281 to 500
29
47
501 to 1,200
34
47
1,201 to 3,200
42
53
3,201 to 10,000
50
68
10,001 to 35,000
60
77
4.4.3 Disposition of sample units. Lot sample units, which have passed group A or B inspections may
be supplied on the contract or purchase order if the lot is accepted.
4.5 Test methods.
4.5.1 Examination of product. Connectors shall be examined for compliance with the dimensions and
workmanship requirements of this specification and in accordance with the applicable specification sheets.
4.5.2 Insulation resistance (see 3.6.1). Unmated connector assemblies shall be tested in accordance
with test procedure EIA/ECA-364-21 the insulation resistance shall not exceed the values specified in
3.6.1. Electrification time shall not exceed 2 minutes.
4.5.3 Withstanding voltage (see 3.6.2). The unmated connectors shall be tested in accordance with
test procedure EIA-364-20. The connectors shall show no evidence of flashover when the applicable
voltage of table III is applied between any contact and any other contact or shell and held for a period of 1
minute. For coaxial contacts, the test voltage of table III shall be applied between the center conductor
and the outer conductor.
