MIL-DTL-24231/11E(SH)
2 TO 8 RECEPTACLES AS REQD M24231/11-004 SYM NO. 516
EIGHT 3-COND RECEPTACLES M24231/11-005 SYM NO. 516.1
TEN 3-COND RECEPTACLES M24231/11-006 SYM NO. 516.2
SEE REQUIREMENT 12
SCR, MACH
COVER,
12
PLATE, DESIGNATION 16
20
(4 REQUIRED)
M24231/11-008
M24231/11-030
3
16
BODY ASSY
5
M24231/11-009
O-RING, GASKET
M24231/25-002 (REFERENCE)
13
SAE-AS28775-334
WIRE/CABLE
17 18
SEE REQT 5
OUTBOARD
INBOARD
RETAINER PLATE
O-RING, GASKET
7
14
M24231/11-021
SAE-AS28775-332
NUT, M24231/10-042 OR
WASHER
10
9
M24231/11-031, SEE REQT 13
M24231/10-043
RING, RETAINING 15
M24231/10-045
PACKING
6
M24231/11-011
ASSY RETAINER PLATE
8
M24231/11-020
NUT, GLAND
4 SLEEVING
M24231/10-044 11
SEE REQT 10
3
1
2
FIGURE 1. Connector, multiple cable (two-piece body).
3
