MIL-DTL-24231/12E(SH)
3
2
1
SAME AS M24231/5-010
EXCEPT AS SHOWN.
1
16
PIN CONTACT
15
(3 REQD)
+1
13 32
32 - 1
32
SOLDER CONDUCTORS
AND SHIELD TO PINS
MOLDED EPOXY
18
AS SHOWN IN TABLE.
RESIN
3
CONNECTIONS
16
FOR M24231/12-020
PIN
COND.
NO.
COLOR
7
16
BLACK
1
2
WHITE
3
SHIELD
15 FT.
CABLE,
17
M24231/12-021
0.255 APPROX.
FIGURE 4. Assembly, insert, molded M24231/12-020.
6
5
