MIL-DTL-24231/17E(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/17- 3/
2/
Description
Material/specification
Remarks
no. 1/
001
1
Connector, adapter,
1
------
See figure 1.
9-conductor, symbol no. 1116.1
2
Body, adapter
1
Ni-Cu, Class A, QQ-N-281
See figure 2 and
requirement 2.
3
Cap, pressure-proof
2
M24231/13-011
See figure 1.
4/
4
Gasket, O-ring
2
SAE-AS28775-213
Lubricate with silicone
compound, SAE-AS8660;
see figure 1.
4/
5
Gasket, O-ring
2
SAE-AS28775-220
See item 4.
6
Insert
2
Nylon, M24231/5-077
See figure 1.
7
Insert assembly, molded
1
See items 10 and 11 or 12 and
See figure 3.
13.
8
Ring, retaining
1
M24231/7-041
See figure 1.
9
Pin, driv-lok,
1
Type A3, CRES 416, coml
See figure 2.
/16 diameter by 3/8 long
1
10
Pin, contact
18
MIL-DTL-24231
See figure 3.
11
Cable, RG-264 C/U
As required
See figure 3 and
requirement 3.
12
Cable, RG-264 A/U
As required
See figure 3 and
requirement 3.
5/
13
Epoxy resin, molded
As required
Cast epoxy resin compound
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo Drive,
Lexington, KY 40509, CAGE 02697, or equal.
5/
Arco Set 200, M.M. Reif and Co., Ivyland, PA, or PR610-TCF (Chockfast Orange), ITW Philadelphia Resins
Corp., Montgomeryville, PA, or equal.
