MIL-DTL-24231/20E(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/20- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
1
Receptacle, 65-conductor
1
------
See figure 1.
symbol no. 1138.1
2
Body, receptacle
1
Ni-Cu, Class A, QQ-N-281
See figure 2.
3
Insert assembly, molded
1
See items 04, 10, and 12.
See figure 3.
4
Pin, contact
65
MIL-DTL-24231
See figure 3.
4/
5
Gasket, O-ring
1
SAE-AS28775-334
Lubricate with silicone
compound, SAE-AS8660;
see figure 1.
4/
6
Gasket, O-ring
1
SAE-AS28775-236
Same as item 5.
7
Ring, retaining
1
M24231/19-011
See figure 1.
8
Insert
1
M24231/5-077
See figure 1.
9
Cap, pressure-proof
1
M24231/22-054
See figure 1.
10
Wire
As required
MIL-DTL-16878/36 BJE0
See figure 3.
11
Pin, guide, 0.125 diameter,
1
Ni-Cu, Class A, QQ-N-281
See figure 1.
length as required
5/
12
Epoxy resin, molded
As required
Cast epoxy resin compound
See figure 3.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Nitrile (Buna N); Parker Hannifin Corporation (part number N0756-75), O-ring Division, 2360 Palumbo
Drive, Lexington, KY 40509, CAGE 02697, or equal.
5/
Arco Set 200, M.M. Reif and Co., Ivyland, PA, or PR610-TCF (Chockfast Orange), ITW Philadelphia
Resins Corp., Montgomeryville, PA, or equal.
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
