MIL-DTL-24231/27F(SH)
1
M24231/27-001 FOR 2SWF-3 CABLE SYM. NO. 1271
ASSEMBLY
M24231/27-002 FOR 2SWF-4 CABLE SYM. NO. 1271.1
2
RECEPTACLE
3
M24231/27-003 FOR 2SWF-7 CABLE SYM. NO. 1271.2
RING, RETAINING
13
M24231/10-041
GASKET, O-RING 8
SAE-AS28775-329
CAP,
12
M24231/14-011
NYLON INSERT
10
M24231/5-077
ASSEMBLY,
4
RECEPTACLE
GASKET, O-RING
9
BODY,
SAE-AS28775-220
M24231/14-010
PIN,
11
M24231/12-012
5
ASSEMBLY, INSERT, MOLDED M24231/26-020
6
ASSEMBLY, INSERT, MOLDED M24231/26-030
7
ASSEMBLY, INSERT, MOLDED M24231/26-040
FIGURE 1. Connector, multi-pin receptacle.
