MIL-DTL-24231/29A(SH)
SOCKET CONTACT 11 OR 12
PREFORM RING
COMPOUND, POLYURETHANE 10
(FOR INFO ONLY)
13 OR 14 PLASTIC SLEEVING
LOADING PIN
PIN ALIGNING HEAD
(FOR INFO ONLY)
(FOR INFO ONLY)
FIGURE 1. Preform insert assembly, typical.
TABLE I. Insert assembly.
Item no.
Name
Use with plug
Symbol no.
1
Insert Assembly
M24231/1-001
713
M24231/2-001
713.5
2
M24231/1-002
713.6
M24231/2-002
713.8
3
M24231/23-001
713.9
4
M24231/3-001
713.1
5
M24231/3-002
713.7
6
M24231/4-001
713.2
M24231/4-006
7
M24231/4-002
713.3
M24231/4-007
8
M24231/4-003
713.4
M24231/4-008
9
M24231/4-004 or
713.10
M24231/4-005
--------
--------
M24231/4-009
15
M24231/1-003
--------
M24231/2-003
--------
2
