MIL-DTL-24231/4E(SH)
MOLDED PLUG ASSEMBLY
M24231/4-001 (14 COND) SYM NO. 713.2
1
OR
M24231/4-002 (24 COND) SYM NO. 713.3
2
OR
M24231/4-003 (30 COND) SYM NO. 713.4
3
OR
M24231/4-004 (40 COND) SYM NO. 713.10
4
OR
M24231/4-005 (40 COND) 5
17
Ø215
6
CABLE TYPE AND LENGTH
AS SPECIFIED IN THE
CONTRACT OR ORDER.
3 MIN
22 COMPOUND, EPOXY
COMPOUND,
16
POLYURETHANE
SOFT SOLDER
TO CONDUCTORS
115
6
45°
1
9
32
PLUG SLEEVE
12
10
M24231/4-010
COUPLING
M24231/4-011
INSERT ASSEMBLY 18 19 20 21
FIGURE 1. Connector, plug, molded typical.
2
