MIL-DTL-24231/6F(SH)
TABLE I. Parts list.
Quantity for
Item
M24231/6- 3/
2/
no.
Description
Material/specification
Remarks
1/
001
1
Connector assembly, single
1
-----
See figure 1.
cable, symbol no. 517.4
2
Gasket, O-ring
1
SAE-AS28775-215
Lubricate with silicone
compound SAE-AS8660,
see figure 1.
3
Gasket, O-ring
1
SAE-AS28775-329
See item 2.
4
Gasket, O-ring
1
SAE-AS28775-327
See item 2.
5
Gasket, O-ring
1
SAE-AS28775-115
See item 2.
6
Single cable connector body
1
Ni-Cu-Al, QQ-N-286
See figure 2 and
continuation of figure 2.
7
Cap, pressure-proof
1
MIL-DTL-24231/12-011
See figure 1.
8
Ring, retaining
1
M24231/5-073
See figure 1.
9
Ring, retaining
1
M24231/5-076
See figure 1.
10
Insert assembly, molded
1
See items 21, 22, and 23
See figure 4.
11
Packing, Class A,
1
Rubber, ZZ-R-768
See figure 5.
durometer, 555
12
Washer, body
1
M24231/5-075
See figure 1.
13
Nut, body
1
M24231/5-074
See figure 1.
14
Ring, gland
1
Ni-Al-BRZ, ASTM B150/B150M See figure 7.
15
Washer, spring lock
1
NASM35338-124
See figure 1.
16
Nut, gland
1
Ni-Al-BRZ, ASTM B150/B150M See figure 6.
17
Pin, guide
1
M24231/5-071
See figure 1.
Plate, identification, 1/16 thick
18
1
CRES or Al, MIL-DTL-15024
See figure 3.
19
Insert
1
M24231/5-077
See figure 1.
20
Screw
2
M24231/5-083
See figure 1.
21
Pin, contact
3
MIL-DTL-24231
See figure 4.
22
Cable, DSS-3, 15
1
MIL-DTL-915/8
4/
23
Epoxy resin, molded
As required
Cast epoxy resin compound
See figure 4.
NOTES:
1/
Item numbers are the same as encircled numbers shown on figures.
2/
See applicable figure or table listed in remarks column for part numbers and dimensions.
3/
Quantity is for one complete assembly of each size.
4/
Arco Set 200, M.M. Reif and Co., Ivyland, PA, or PR610-TCF (Chockfast Orange), ITW Philadelphia
Resins Corp., Montgomeryville, PA, or equal.
9
