MIL-DTL-24231/7F(SH)
9. Tolerances shall be as follows, or as stated:
Decimals ±0.005 inch.
a.
Fractions ±1/64 inch.
b.
Angular dimensions ±½ degree.
c.
d.
Tolerances for rubber packing should follow the guidance provided in table XLI (RMA Drawing
Designation A2 Precision) of MIL-HDBK-149.
10. The flange outside diameter is intended to coincide with commonly available 2¾-inch bar stock. The
dimension may vary after machine clean-up.
9
INSERT, NYLON
CAP, M24231/13-011
7
RING, RETAINING
19 M24231/7-041
GASKET, O-RING,
3
SAE-AS28775-220
SCREW,
12 M24231/5-083
GASKET, O-RING,
6
SAE-AS28775-213
PLATE, IDENT
21 M24231/7-051
GASKET, O-RING,
4
SAE-AS28775-329
1
PIN, M24231/5-071
15 SEE REQT 4 AND 6.
ASSY, INSERT, MOLDED,
8
M24231/7-010
1
23 WIRE
ASSY, SINGLE CABLE CONNECTOR
2
BODY, M24231/7-040
PLATE, RETAINER, M24231/7-031 10
GASKET, O-RING,
5
1
SAE-AS28775-327
PACKING, M24231/7-032 20
2
ASSY, RETAINER PLATE,
11 24
M24231/7-030
WASHER,
13 M24231/5-075
NUT, M24231/5-074 14
2
RING, RETAINING 22
M24231/5-076
SLEEVING - 14 FT. LG 18
NUT, GLAND
16 M24231/5-072
0.430 I.D. X 0.030 THK.
SEE REQT 3.
1
HARDNESS READING TO BE TAKEN AT THESE POINTS.
2
HARDNESS READING TO BE TAKEN AT THIS FACE AT
120-DEGREE INTERVALS.
FIGURE 1. Connector, seven-conductor M24231/7-001, symbol no. 517.1.
