MIL-DTL-24308/23G
PIN: Consists of the letter M, the basic number of the specifications sheet, and a dash number compiled from the
code.
-50
F
PIN example:
M24308/23
Specification sheet number
Dash sheet number from table I
Finish: For class G and N:
A = Pure electrodeposited aluminum.
F = Cadmium .
K = Zinc nickel.
T = Nickel Fluorocarbon Polymer.
Z or No suffix = zinc. (See MIL-DTL-24308 for disposition of stock for "No suffix" finish)
For class M:
Class M connectors have a gold finish, no suffix is required.
For class D:
Class D connectors have a nickel finish, no suffix is required.
Changes from previous issue: The margins of this specification are marked with vertical lines to indicate where
changes from previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Referenced documents. In addition to MIL-DTL-24308, this document references the following:
MIL-DTL-24308/3
MIL-DTL-24308/4
MIL-DTL-24308/6
MIL-DTL-24308/24
IPC-CC-830
