MIL-DTL-24308/25K
Finish: Cold rolled and sheet steel - Yellow chromate over cadmium in accordance with SAE-AMS-QQ-P-416 or zinc
nickel alloy in accordance with ASTM B841 an underplate is optional or Nickel fluorocarbon polymer an underplate is
optional or pure electrodeposited aluminum in accordance with MIL-DTL-83488.
Screw (Cold rolled steel) - Yellow chromate over zinc in accordance with ASTM B633 or an equivalent industry
standard when available.
Clip (sheet steel) - Yellow chromate over zinc in accordance with ASTM B633 or an equivalent industry standard
when available or aluminum coating.
Corrosion resistant steel - Shall be passivated in accordance with SAE-AMS-2700.
Screws shall be captive in the clip after assembly by the end user and corrosion resistant steel screws shall be used
with corrosion resistant steel clips and cold rolled screws shall be used with sheet steel clips.
Qualification inspection: The following tests shall be performed on 3 samples (defined below) in accordance with
MIL-DTL-24308:
Visual examination
Shock
Vibration
Visual examination
Test sample: Each sample shall consist of a M24308/25 dash number assembled to the applicable pair of mated
connectors with M24308/26-1 or M24308/26-2 attached.
Part or Identifying Number (PIN) example:
M24308/25 -
6
P
(Dash number on figure 1).
Finish
A = Pure electrodeposited aluminum.
F = Cadmium
K = Zinc nickel.
P = Passivated stainless steel.
T = Nickel fluorocarbon polymer.
Z or No suffix = zinc (See MIL-DTL-24308 for disposition of stock)
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
