MIL-DTL-24308/4P
PIN: Consists of the letter M, the basic number of the specification sheet, and a dash number compiled from the
code.
PIN example:
M24308/4
-361
F
Specification sheet number
Data sheet number from table I
Finish: For class G:
A = Pure electrodeposited aluminum.
F = Cadmium .
K = Zinc nickel.
T = Nickel Fluorocarbon Polymer.
Z or No suffix = zinc. (See MIL-DTL-24308 for disposition of stock for "No suffix" finish)
For class D:
Class D connectors have a nickel finish, no suffix is required.
Supersession data: See table II.
TABLE II. Shell supersession data.
Shell detail
Superseded MS sheet
(see figure 1)
Detail A
MS18271-1 through 6
Detail B
MS18271-7 through 12
Detail D
MS18271-13 through -18
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with vertical lines to indicate
where changes from previous issue were made. This was done as a convenience only and the Government
assumes no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal notations and
relationship to the last previous issue.
Referenced documents. In addition to MIL-DTL-24308, this document references the following:
MIL-DTL-24308/1
MIL-DTL-24308/2
MIL-DTL-24308/23
8
