MIL-DTL-2726/14C
REQUIREMENTS
Dimensions and configurations: See figures 1 and 2.
Effectiveness of enclosure: Watertight in accordance with MIL-STD-108.
Enclosure assembly: See table I.
Receptacle unit: See table I.
Cap assembly: MIL-DTL-2726/13, Part or Identifying Number (PIN): M2726/13-001.
Material: For symbol number 1145.3, box and cover with receptacle unit, integral, shall be of
molded plastic in accordance with ASTM-D5948 type MAI-60.
Mating plug: MIL-DTL-2726/5, PIN M2726/5-001 (not furnished).
Electrical rating: 40 ampere, 450 volt, alternating current, 60-hertz.
PIN: See table I.
TABLE I. Assembly parts,
PIN
Symbol number
Box
Cover
Receptacle unit
M24142/5-002
M2726/11-001
M2726/14-001
1145.1
M24142/5 (metal)
(metal)
(metal housing)
M24142/5-002
M2726/11-002
M2726/14-002
1145.2
M24142/5-002 (metal)
(metal)
(plastic)
Molded plastic (see
M2726/11-002
(see requirement 6)
M2726/14-003
1145.3
requirement 6)
(integral with cover)
M2726/14-004
------
------
See figure 2
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table II herein. The first article
and quality conformance inspections shall consist of the inspections as specified in table II,
in the order shown.
5
