MIL-DTL-2726/36C
REQUIREMENTS
Dimensions and configuration: See figure 1.
Contact resistance: When tested as specified in accordance with MIL-DTL-2726, the voltage drop
shall not exceed 20 millivolts. Measured between the end of a 12.000-inch
length of AWG number 6 stranded copper wire properly connected to the test
plug, and the connection stud of the receptacle.
Uncoupling force: Minimum of 8 pounds; maximum of 20 pounds.
High Impact shock: Disengagement of the test plug from the receptacle under High Impact shock
shall not be considered as a failure.
Contact hardness: Minimum of Rockwell 76B.
Mating plug: MIL-DTL-2726/34, Part or Identifying Number (PIN) M2726/34-001 red;
PIN M2726/34-002 black.
Design: Panel hole .906 inch diameter. Panel thickness .062 to .250 inch.
Material: Body and cap rubber, in accordance with ASTM-D2000, M2AC 710 A13E034, or plastic
in accordance with ASTM-D5948 MAI-60.
Electrical rating: 40-ampere, 125-volt, single pole.
PIN: M2726/36-001 (red), symbol 1213.3, M2726/36-002 (black), symbol 12213.5.
Contact finish: Silver plate.
Verification
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and quality conformance inspection.
First
Conformance
Inspection
article
X
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
X
Contact resistance
X
Uncoupling force
X
X
Endurance
X
Uncoupling force
X
Salt spray
X
Contact resistance
X
Current load
X
Vibration
X
Shock
X
Dielectric withstanding voltage
X
Rockwell hardness
