MIL-DTL-2726/37G
Intended use: Shipboard, for electronic test equipment on radar platforms and open bridges and
portable battery charging units. Watertight when secured (not in use). May be used
with watertight or non-watertight plug.
PIN: M2726/37-001 complete receptacle.
M2726/37-001-1 receptacle fitting.
Cap assembly: Material shall be plastic or brass.
Verification
Verification shall be specified in MIL-DTL-2726 and table I herein. The first article and conformance
inspections shall consist of the inspections as specified in table I, in the order shown.
TABLE I. First article and quality conformance inspection.
First
Quality
Inspection
conformance
article
Examination
X
X
Endurance
X
Ground contact resistance
X
X
Vibration
X
Shock
X
Salt spray
X
Effectiveness of enclosure
X
X
Dielectric withstanding voltage
X
Changes from previous issue. The margins of this specification are marked with vertical lines to
indicate where changes from the previous issue were made. This was done as a convenience only
and the Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders
and contractors are cautioned to evaluate the requirements of this document based on the entire
content irrespective of the marginal notations and relationship to the last previous issue
Reference documents. In addition to MIL-DTL-2726, this document references the following:
MIL-DTL-2726/38
MIL-E-24142/9
MIL-STD-108
UL817
CONCLUDING MATERIAL
Custodians:
Preparing activity
Navy - SH
DLA - CC
DLA - CC
(Project 5935-2008-143)
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above
using the ASSIST Online database at https://assist.daps.dla.mil.
3
