MIL-DTL-2726/49F
The outlet shall be used for operating a group of up to three portable submersible pumps.
PIN: M2726/49-002 (includes -1, -2, and -3).
Bond the rubber packing grommet to the cable by a bonding agent such as Gates Engineering Co.
N-29 or equal, accelerated with N-39 or equal; coat inner surface of hole in grommet.
Provide rubber boot over ground clip on PIN M2726/49-002-2.
Molded parts containing markings based on drawings that have been superseded may continue to
use the superseded markings until the molds require renewal.
Plug: In accordance with MIL-DTL-24552/4, PIN M244552/4-001 symbol 1049.
General information is specified in table I.
TABLE I. General information.
Symbol
PIN
Used with portable submersible pumps and
number
required
hoists in systems using:
765.6
M2726/49-002-1 No casualty equipment
M2726/49-002-1 Casualty power equipment in accordance
765.7
M2726/49-002-2 with MIL-T-24381 1/
M2726/49-002-1 Casualty power equipment in accordance
765.8
M2726/49-002-3 with MIL-DTL-24552
1/ Replacement only, not for new construction.
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article and
conformance inspections shall consist of the inspections as specified in table II, in the order shown.
TABLE II. First article and conformance inspection.
First
Inspection
Conformance
article
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding voltage
X
X
Vibration
X
Shock
X
Salt spray
X
Effectiveness of enclosure
X
X
Dielectric withstanding voltage
X
Leakage current
X
X
The margins of this specification are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
8
