MIL-DTL-2726/59B
REQUIREMENTS
Dimensions and configuration: See figure 1.
Effectiveness of enclosure: Watertight in accordance with MIL-STD-108 when
mounted in a suitable enclosure.
Material: Housing optional polymide (nylon) or metal.
Contact insulation in accordance with type MAI-60 of ASTM-D5948.
Contact hardness: Minimum of Rockwell 80F.
Mating Plug: MIL-DTL-2726/54, Part or Identifying Number (PIN): M2726/54-001.
Design: Plastic housing and insulation may be a one-piece molded unit.
PIN: M2726/59-001.
Electrical rating: 10-ampere, 450-volt, alternating current, 400-hertz.
VERIFICATION
Verification shall be as specified in MIL-DTL-2726 and table I herein. The first article
and conformance inspections shall consist of the inspections as specified
in table I, in the order shown.
TABLE I. First article and conformance inspection.
Inspection
First article
Conformance
Examination
X
X
Insulation resistance
X
X
Dielectric withstanding Voltage
X
X
Contact resistance
X
X
Endurance
X
Salt spray
X
Contact resistance
X
Current load
X
Vibration
X
Shock
X
Effectiveness of enclosure
X
X
Dielectric withstanding voltage
X
Rockwell hardness
X
Marginal notations are not used in this revision to identify changes with respect to the previous issue
due to the extensiveness of the changes.
