INCH-POUND
MIL-DTL-2726/8B
14 February 2006
SUPERSEDING
MIL-R-2726/8A(SH)
3 July 1986
DETAIL SPECIFICATION SHEET
RECEPTACLE, ELECTRICAL, 3-PIN GROUNDED, 50-AMPERE, 250-VOLT,
DIRECT CURRENT (SYMBOL NOS. 757.1 AND 757.2)
Inactive for new design as of 28 June 1999.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this
specification sheet and MIL-DTL-2726.
SH 9079 symbol no. 757.1
FIGURE 1. Receptacle (metal housing and shell).
AMSC N/A
FSC 5935
