INCH-POUND
MIL-DTL-27434/38B
22 May 2008
SUPERSEDING
MIL-A-27434/38A
3 June 1964
DETAIL SPECIFICATION SHEET
ADAPTER, CONNECTOR, COAXIAL, RADIOFREQUENCY,
BETWEEN SERIES, SERIES N to SERIES LN
TYPE UG-213A/U
Inactive for new design after
19 February 1982
This specification is approved for use by all Departments
and Agencies of the Department of Defense
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-27434.
Inches mm
.015 0.38
.875 22.23
1.531 38.89
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
FIGURE 1. Type UG213A/U connector adapter.
AMSC N/A
FSC 5935
