MIL-DTL-28748/10G
1.090
±.010
.990
.923
±.010
±.010
.550
.287
±.005
φ.149 ±.006 THRU
±.010
MOUNTING HOLE OR
C
.218
L
MOUNTING SLEEVE
.81
±.010
(SEE DETAIL A) TYP
A
C
.25
JACKSCREW
.250-28 UNF-2A
.437
SEE JACKSCREW
HEX
TABLE
2.275
X
Y
±.010
.225
.300
W
1.900
C
Z
L
±.005
.150
.375 .450 .600
1.555
N
V
.525 .675
±.010
POLARIZING BOSS
IN "N" POSITION
D
B
SEE JACKSCREW TABLE
.130
060 R
1.77
.260
TYP
MAX
.390
φ.246 ±.002
.156 R
TYP
GUIDE PIN
SEE GUIDE PIN TABLE
φ.149 ±.006
φ .149 ±.006
POLARIZING
BOSS "N"
.250
POSITION SHOWN
.55
(NORMAL)
MOUNTING HOLE
MOUNTING
SLEEVE
.002
.225
DETAIL A
Inches
mm
Inches
mm
Inches
mm
.002
0.05
.246
6.25
.550
13.97
.005
0.13
.250
6.35
.600
15.24
.006
0.15
.260
6.60
.675
17.15
.010
0.25
.287
7.29
.81
20.6
.060
1.52
.300
7.62
.923
23.44
.130
1.91
.375
9.53
.990
25.15
.149
3.78
.390
9.91
1.090
27.69
.150
3.81
.437
11.10
1.555
39.50
.156
3.96
.450
11.43
1.900
48.26
.225
5.72
.525
13.34
2.275
57.78
Insert with through mounting hole configuration D.
Insert with mounting sleeve configuration M.
FIGURE 6. Insert configuration with 52 positions.
