MIL-DTL-28804/7E
Mating connectors: M28804/7-1 through -6 mates with M28804/2-1 through -6, M28804/4-1
through -6, M28804/6-1 through -6, M28804/8-1 through -6, and M28804/11-1 through -6. M28804/7-7
through -12, mates with M28804/2-7 through -12, M28804/4-7 through -12, M28804/6-7 through -12,
M28804/8-7 through -12, and M28804/11-7 through -12.
Part or Identifying Number (PIN): M28804/7-(dash number from figure 1 and a suffix letter code to
define polarization. See figure 1, note 4 herein, and MIL-DTL-28804.)
Dielectric withstanding voltage shall be in accordance with MIL-DTL-28804, except that the test
voltages shall be as specified in table I.
TABLE I. Test voltage (rms 60 Hz ac volts). 1/
Altitude
Moisture conditioned samples
All other
(feet)
(see MIL-DTL-28804)
samples
Sea level
600
1200
(70,000)
500
1/ These are not working voltages.
Referenced documents. In addition to MIL-DTL-28804, this document references the following:
MIL-DTL-28804/10
MIL-STD-1632
Changes from previous issue. The margins of this specification are marked with vertical lines to
indicate where changes from the previous issue were made. This was done as a convenience only and
the Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
CONCLUDING MATERIAL
Custodians:
Preparing activity:
Army CR
DLA CC
Navy EC
Air Force 11
(Project 5935-4824-000)
DLA - CC
Review activities:
Army AM, AR, AT, CR4, MI
Navy AS, MC
Air Force 99
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil.
