MIL-DTL-28840/10E
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Insert arrangements: See the MIL-STD-1698 figure corresponding to the desired shell size.
Shell polarization: 1 thru 6, key position.
Marking: Mark Part or Identifying number (PIN) on the shell.
Mating counterpart: Plug connectors specified in MIL-DTL-28840/16 through /19, /26, /28 and /29.
Installation and removal tools: As specified in MIL-I-81969/33 and /34.
A backshell shall be used to meet moisture and water pressure requirements.
PIN example:
M28840/10
A
G
1
P
1
Specification sheet number
Key position
1, 2, 3, 4, 5, 6 position
Classes
Code letter
D
A
Contact designator
DS
B
P
F
T
L
TS
N
Z
S
ZS
R
Shell size
Insert designator
RESTRICTIONS:
Classes D and DS are inactive for NAVSEA new design, unless approved by NAVSEA.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents. In addition to MIL-DTL-28840, this document references the following:
MIL-DTL-28840/16
MIL-DTL-28840/17
MIL-DTL-28840/18
MIL-DTL-28840/19
MIL-DTL-28840/26
MIL-DTL-28840/28
MIL-DTL-28840/29
MIL-I-81969/33
MIL-I-81969/34
MIL-STD-1698
