MIL-DTL-28840/11D
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Classes: D, DS, P, T, TS, Z and ZS.
Insert arrangements: See the figure of MIL-STD-1698 corresponding to the desired shell size.
Contacts: Pin or socket, crimp type, styles P, S, D, E, F or G, in accordance with MIL-DTL-28840.
Shell polarization: 1 thru 6, key position.
Marking: Part or Identifying Number (PIN) on shell.
Mating counterpart: Plug connectors specified in MIL-DTL-28840/16, /17, /18, /19, /26, /28, and /29.
Installation and removal tools: As specified in MIL-I-81969/33 and /34.
A backshell shall be used to meet moisture and water pressure requirements.
PIN example:
M28840/11
A
G
1
P
1
Specification sheet number
Key position
1, 2, 3, 4, 5, 6 position
Classes
Code letter
D
A
Contact designator
DS
B
P
F
T
L
TS
N
Z
S
ZS
R
Shell size
Insert designator
Restrictions:
Classes D and DS are inactive for NAVSEA new design, unless approved by NAVSEA.
3
