MIL-DTL-28840/12F
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 2, and tables I through IV.
This connector mates with MIL-DTL-28840/16, /17, /18, /19, /26, /28 and /29.
Insert arrangements: See the figure of MIL-STD-1698 corresponding to the desired shell size.
Connector accessories: See MIL-DTL-28840 supplement.
Class code letters:
TABLE II. Class code letter for figures 1 and 2.
Class
Class code letter
D
A
DS
B
P
F
T
L
TS
N
Z
S
ZS
R
Contacts: Pin or socket, crimp type, styles P, S, D, E, F or G, in accordance with MIL-DTL-28840.
Shell polarization: 1 through 6, key position.
Installation and removal tool: In accordance with MIL-I-81969/33 and /34.
Normal mating keyway position is shown on figures 1 and 2. For alternate keyway positions,
see MIL-DTL-28840.
Figure 1 connector shall be supplied with resilient wire separator in lieu of a wire seal grommet.
Figure 2 connector shall be supplied with a wire seal grommet.
Part or Identifying Number (PIN) example.
M28840/
12
A
2
G
1
P
1
Military designator
Specification sheet
Class code letter
(See table II)
Figure 1----Normally blank (omitted)
Figure 2----2
Shell size
(See table I)
Insert arrangement
(See table I and MIL-STD-1698)
Contact designator
(See MIL-DTL-28840)
Key position
(See MIL-DTL-28840)
4
