MIL-DTL-28840/16D
Q
Shell size
designator
dia
(See note 3)
max
A (11)
1.028 (26.11)
B (13)
1.141 (28.98)
C (15)
1.263 (32.08)
D (17)
1.387 (35.23)
E (19)
1.513 (38.43)
F (23)
1.703 (43.26)
G (25)
1.825 (46.36)
H (29)
2.143 (54.43)
J (33)
2.329 (59.16)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Shell sizes are provided within parentheses for information and are not a part of the designator.
4. Dimensions apply after plating.
5. Normal mating key position shown. Alternate key positions shall be in accordance with
MIL-DTL-28840.
FIGURE 1. Dimensions and configuration Continued.
