MIL-DTL-28840/20H
Assembly
Connector
Backshell
B
Shell size
E
L
(PIN)
receptacle
assembly
thread
designator
ref
max
(see note 6)
(PIN)
(PIN)
class 2B
(see note 3)
(see note 6)
(see note 6)
.938
6.625
A (11)
M28840/20*A*A***
M28840/10*A***
M28840/601**
.750-.1P.2L-D.S.
(23.83)
(168.28)
1.125
6.625
A (11)
M28840/20*A*B***
M28840/10*A***
M28840/624**
.750-.1P.2L-D.S.
(28.58)
(168.28)
1.312
6.625
A (11)
M28840/20*A*C***
M28840/10*A***
M28840/625**
.750-.1P.2L-D.S.
(33.32)
(168.28)
.938
6.625
B (13)
M28840/20*B*A***
M28840/10*B***
M28840/602**
.875-.1P.2L-D.S.
(23.83)
(168.28)
1.125
6.625
B (13)
M28840/20*B*B***
M28840/10*B***
M28840/603**
.875-.1P.2L-D.S.
(28.58)
(168.28)
1.312
6.625
B (13)
M28840/20*B*C***
M28840/10*B***
M28840/626**
.875-.1P.2L-D.S.
(33.32)
(168.28)
1.312
7.125
B (13)
M28840/20*B*D***
M28840/10*B***
M28840/627**
.875-.1P.2L-D.S.
(33.32)
(180.98)
1.125
6.625
C (15)
M28840/20*C*A***
M28840/10*C***
M28840/605**
1.062-.1P.2L-D.S.
(28.58)
(168.28)
1.312
6.625
C (15)
M28840/20*C*B***
M28840/10*C***
M28840/606**
1.062-.1P.2L-D.S.
(33.32)
(168.28)
1.312
7.125
C (15)
M28840/20*C*C***
M28840/10*C***
M28840/628**
1.062-.1P.2L-D.S.
(33.32)
(180.98)
1.593
7.188
C (15)
M28840/20*C*D***
M28840/10*C***
M28840/607**
1.062-.1P.2L-D.S.
(40.46)
(182.58)
.938
6.625
C (15)
M28840/20*C*E***
M28840/10*C***
M28840/604**
1.062-.1P.2L-D.S.
(23.83)
(168.28)
1.312
7.125
D (17)
M28840/20*D*A***
M28840/10*D***
M28840/608**
1.125-.1P.2L-D.S.
(33.32)
(180.98)
1.593
7.188
D (17)
M28840/20*D*B***
M28840/10*D***
M28840/609**
1.125-.1P.2L-D.S.
(40.46)
(182.58)
1.750
7.188
D (17)
M28840/20*D*C***
M28840/10*D***
M28840/610**
1.125-.1P.2L-D.S.
(44.45)
(182.58)
1.312
7.125
E (19)
M28840/20*E*A***
M28840/10*E***
M28840/611**
1.312-.1P.2L-D.S.
(33.32)
(180.98)
1.750
7.250
E (19)
M28840/20*E*B***
M28840/10*E***
M28840/612**
1.312-.1P.2L-D.S.
(44.45)
(184.15)
1.593
7.688
F (23)
M28840/20*F*A***
M28840/10*F***
M28840/613**
1.500-.1P.2L-D.S.
(40.46)
(195.28)
1.750
7.812
F (23)
M28840/20*F*B***
M28840/10*F***
M28840/614**
1.500-.1P.2L-D.S.
(44.45)
(198.42)
2.093
7.938
F (23)
M28840/20*F*C***
M28840/10*F***
M28840/615**
1.500-.1P.2L-D.S.
(53.16)
(201.63)
FIGURE 1. Dimensions and configuration Continued.
