MIL-DTL-28840/23D
A
B
Designator
thread
dia
(see note 1)
max
class 2B
A (11)
.750-20 UNEF
1.028 (26.11)
B (13)
.875-20 UNEF
1.141 (28.98)
C (15)
1.000-20 UNEF
1.263 (32.08)
D (17)
1.125-18 UNEF
1.387 (35.23)
E (19)
1.250-18 UNEF
1. 513 (38.43)
F (23)
1.438-18 UNEF
1.703 (43.26)
G (25)
1.562-18 UNEF
1.825 (46.35)
H (29)
1.876-16 UN
2.143 (54.43)
J (33)
2.062-16 UNS
2.329 (59.16)
NOTES:
1. Shell sizes are provided within parentheses for information and are not a part of the
designator.
2. Dimensions are in inches.
3. Metric equivalents are given for information only.
4. Dimensions apply after plating.
5. These gland nuts are used with MIL-DTL-28840/10, /11, /14 and /16.
FIGURE 1. Dimensions and configurations - Continued.
2
