MIL-DTL-28840/4B
A
B
Nominal conduit
Size
dia
L
dia
inside dia
over shield
max
± .010 (0.25)
over jacket
03
.375 (9.52)
.525 (13.34)
.688 (17.47)
04
.500 (12.70)
.650 (16.51)
.812 (20.62)
05
.625 (15.87)
.765 (19.43)
.937 (23.79)
50 ft.
06
.750 (19.05)
.925 (23.50)
1.078 (27.38)
max
08
1.00 (25.40)
1.210 (30.73)
1.437 (36.49)
10
1.25 (31.75)
1.455 (36.96)
1.695 (43.05)
12
1.500 (38.10)
1.725 (43.82)
1.956 (49.68)
16
2.000 (50.80)
2.200 (55.88)
2.469 (62.71)
NOTES:
1. Dimensions are in inches.
2. Unless otherwise specified, tolerances are ± .016 inch (0.41 mm).
3. Metric equivalents are given for information only.
4. For protective cover, see MS17349.
FIGURE 1. Dimensions and configuration Continued.
REQUIREMENTS:
Design and construction: See figure 1.
Materials:
Material conduit:
Type C: Brass foil.
Braid:
Low phosphorous bronze wire.
Insulator jacket:
Neoprene.
Material conduit:
Type E: Nickel iron foil.
Braid:
Tinned coated copper.
Insulator jacket:
Neoprene.
Length and tolerance in length should be specified through the ordering data.
