MIL-DTL-28840/5D
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Interface dimensions in accordance with MIL-DTL-28840.
Material and finish: See table I.
TABLE I. Material and finish.
Material and finish
Material
Finish
designator
Aluminum alloy in accordance with
Cadmium plate, olive drab over
ASTM B85/B85M, ASTM B26/B26M,
electroless nickel
W
ASTM B108/B108M, ASTM B209,
ASTM B211, or ASTM B221
Corrosion resistant steel in accordance with
Cadmium plate, black 1/
ASTM A276, ASTM A473, or
D
ASTM A580/A580M, type 316
Pure electro-
F
deposited aluminum,
Aluminum alloy in accordance with
non-reflective
ASTM B85/B85M, ASTM B26/B26M,
Nickel fluorocarbon polymer,
ASTM B108/B108M, ASTM B209,
L
non-reflective
ASTM B211, or ASTM B221
S
Zinc nickel, non-reflective
Nickel fluorocarbon polymer,
Corrosion resistant steel in accordance with
N
non-reflective
ASTM A276, ASTM A473, or
ASTM A580/A580M, type 316
R
Zinc nickel, non-reflective
1/ Screws and washers shall be passivated in accordance with SAE-AMS2700, type 2.
Marking: The backshell shall be identified with the manufacturer's name or trademark and the Part or
Identifying Number (PIN).
PIN example:
M28840/
5
16
W
A
Military designator
Specification sheet number
Dash number
Material and finish designator
(See table I)
Style designator
A EMI / Non-environmental
B EMI / Environmental
5
