MIL-DTL-28840/7E
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Shell polarization: 1 through 6, key position.
Marking: Part or Identifying Number (PIN) on shell.
Mating plugs: This receptacle mates with plugs in accordance with MIL-DTL-28840/16 through /19,
/26, /28, and /29.
Material: Aluminum alloy.
Finish: Finish shall be in accordance with MIL-DTL-28840.
Color: Color shall be in accordance with MIL-DTL-28840. Cadmium finish shall be olive drab.
Sealing gasket: Non-corrosive silicone or fluorosilicone elastomer.
PIN example:
M28840/7
G
1
F
Specification sheet number
Shell size
Key positions:
1, 2, 3, 4, 5, and 6 position
Material and finish designator
No designator aluminum alloy, cadmium plated, olive drab over electroless nickel
F Wrought aluminum, pure electrodeposited aluminum non-reflective
L - Wrought aluminum, nickel fluorocarbon polymer non-reflective
S - Wrought aluminum, zinc nickel, black non-reflective
RESTRICTIONS:
Cadmium finish (no material or finish designator is specified in the PIN) is inactive for NAVSEA new
design, unless approved by NAVSEA.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents. In addition to MIL-DTL-28840, this document references the following:
MIL-DTL-28840/16
MIL-DTL-28840/17
MIL-DTL-28840/18
MIL-DTL-28840/19
MIL-DTL-28840/26
MIL-DTL-28840/28
MIL-DTL-28840/29
