MIL-DTL-3655/16B
Inches
mm
Inches
mm
.022
0.56
.505
12.83
.045
1.14
.510
12.95
.104
4.06
.620
15.75
.114
2.90
.630
16.00
.160
4.06
.796
20.22
.215
5.46
.800
20.32
.493
12.52
.843
21.41
.500
12.70
1.625
41.28
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Dimension .800 is the largest overall diameter of the connector.
4. Wrench flats are to accommodate standard wrench openings in accordance with H-28 appendix 10.
5. All undimensioned pictorial configurations are for reference purpose only.
6. Orientation of the body hex flats, mounting flats, bayonet stubs, contacts, and insulator shall be
within 3 of the orientation shown.
7. Dimensions define the maximum length of the connector when assembled to the appropriate
cable.
FIGURE 1. Type TWBNC, electrical receptacle connector Continued.
ENGINEERING DATA
Nominal impedance: 78 ohms.
Frequency range: DC to 500 MHz, maximum.
Voltage rating: 500 V rms, maximum.
Mating connector: See table I of MIL-DTL-3655/15.
Captive contact retention: 6 pounds, axial.
Intended use: Type MIL-DTL-3655/16 electrical connectors are intended for use with various types
of twin axial radio frequency cables.
2
