MIL-DTL-3655/17A
ENGINEERING DATA
Nominal impedance: 78 ohms.
Frequency range: DC to 500 MHz, maximum.
Voltage rating: 500 V rms, maximum.
Mating connector: MIL-DTL-3655/16 (see table I).
TABLE I. Connector to cable accommodation.
Connector Part or Identifying Number
Cable accommodation 1/
(PIN)
M3655/17-0001
M17/45-RG108 and
M17/186-00001
M3655/17-0002
M17/182-00001
M3655/17-0003
M17/182-00002
1/ The latest version of each cable shall apply.
Captive contact retention: 6 pounds, axial.
Intended use: Type MIL-DTL-3655/17 electrical connectors are intended for use with various types
of twin axial radio frequency cables.
REQUIREMENTS:
Dimensions and construction: See figure 1 and MIL-STD-348.
Force to engage/disengage:
Torque: 2 inch-pounds, maximum.
Longitudinal force: Not applicable.
Coupling proof torque: 15 inch-pounds, minimum.
Mating characteristics (see figure 1 and MIL-STD-348 for dimensions):
Inner contact (sockets):
Oversize test pin: 0.042 inch diameter, minimum (nonclosed entry contacts only).
Test pin finish: 16 microinches.
Insertion depth: .093 inch, minimum.
Number of insertions: One.
Insertion force test:
Steel test pin diameter: .039 inch, minimum.
Test pin finish: 16 microinches.
Insertion depth: .093 inch, minimum.
Insertion force: 2 pounds, maximum.
