MIL-DTL-38999/20G
REQUIREMENTS:
Dimensions and configuration: See figure 1. Interface dimensions shall conform to MIL-DTL-38999.
This connector mates with MIL-DTL-38999/26.
For insert arrangements: See MIL-STD-1560.
Connector accessories: See SAE-AS85049.
Part or Identifying Number (PIN) example:
20
W
A
35
P
N
D38999/
DoD number prefix
Specification sheet number
Class
Shell size code
Insert arrangement
Contact style
Polarizing positions
N is required for normal position
Class F is not for Navy use and is inactive for Air Force new design use.
NOTE: The term PIN is equivalent to the term (part number, identification number, and type designator)
which was previously used in this specification.
Qualification required: The activity responsible for the qualified product list for this specification sheet is
the Defense Supply Center Columbus, DSCC-VQ, 3990 East Broad Street, Columbus, Ohio
43218-3990 .
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-38999, this document references the following:
MIL-DTL-38999/26
MIL-STD-1560
SAE-AS85049
