MIL-DTL-38999/25C
Shell
Shell
F
L
S
V max
V max
Z
size
size code
max
max
max
with pins
with sockets
max
9
A
17.1
5.1
19.4
17.2
19.4
23.8
(.673)
(.201)
(.764)
(.677)
(.764)
(.937)
11
B
19.9
5.1
21.8
17.2
19.4
23.8
(.783)
(.201)
(.858)
(.677)
(.764)
(.937)
13
C
23.1
5.1
24.9
17.2
19.4
23.8
(.909)
(.201)
(.980)
(.677)
(.764)
(.937)
15
D
26.2
5.1
28.1
17.2
19.4
23.8
(1.031)
(.201)
(1.106)
(.677)
(.764)
(.937)
17
E
29.4
5.1
31.3
17.2
19.4
23.8
(1.157)
(.201)
(1.232)
(.677)
(.764)
(.937)
19
F
31.8
5.1
33.6
17.2
19.4
23.8
(1.252)
(.201)
(1.323)
(.677)
(.764)
(.937)
21
G
35.0
5.1
36.8
17.2
19.4
23.8
(1.378)
(.201)
(1.449)
(.677)
(.764)
(.937)
23
H
38.2
5.9
40.0
17.2
19.4
24.6
(1.504)
(.232)
(1.575)
(.677)
(.764)
(.969)
25
J
41.3
5.9
43.2
17.2
19.4
24.6
(1.626)
(.232)
(1.701)
(.677)
(.764)
(.969)
NOTES:
1. Dimensions are in millimeters.
2. Polarizing position N is shown.
3. Inch equivalents are given for information only.
FIGURE 1. Receptacle, classes N and Y - Continued.
