MIL-DTL-38999/41B
NOTES:
1. Dimensions are in millimeters.
2. The gage features for "J" shall be 0.25 mm (.010 in) larger than the maximum material condition
(mmc) size at basic location.
3. Inch-pound conversion are provided in parentheses for information only.
FIGURE 1. Receptacle, classes N and Y - Continued.
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Interface dimensions shall conform to MIL-DTL-38999.
This connector mates with MIL-DTL-38999/46 and /47.
Main key color: Blue.
For insert arrangements: See MIL-STD-1560.
Part or Identifying Number (PIN) example:
D38999/
41
N
B
35
P
N
DOD no. prefix
Specification sheet no.
Class
Shell size code
Insert arrangement
Contact style
P Pin, Solder cup.
X Pin, Eyelet.
Polarizing position:
N is required for normal position.
For contact termination: See MIL-DTL-38999.
3
