MIL-DTL-38999/44D
REQUIREMENTS:
Dimensions and configurations: See figure 1.
Interface dimensions shall conform to MIL-DTL-38999.
This connector mates with the following:
Classes C, F, P, T, W, X and Z shall conform to MIL-DTL-38999/46 and MIL-DTL-38999/47.
Classes K, S and R shall conform to MIL-DTL-38999/46.
Main key color: Blue.
For insert arrangements: See MIL-STD-1560.
PIN example:
D38999/
44
F
A
35
P
N
Polarizing position: N is
required for normal position
Contact style
Insert arrangement
Shell size code
Class
Specification sheet number
DoD prefix
Changes from previous issue. Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Referenced documents. In addition to MIL-DTL-38999, this document references the following:
MIL-DTL-38999/46
MIL-DTL-38999/47
MIL-STD-1560
4
