METRIC
MIL-DTL-38999/50C
5 February 2014
SUPERSEDING
MIL-DTL-38999/50B
11 June 2001
DETAIL SPECIFICATION SHEET
CONNECTORS, ELECTRICAL, CIRCULAR, RECEPTACLE,
DUMMY STOWAGE, BREECH COUPLING, SERIES IV, METRIC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-38999.
mm
Inches
mm Inches
0.13
.005
0.90 .035
0.40
.016
20.02 .788
FIGURE 1. Dummy receptacle, classes T, W, X and Z.
AMSC N/A
FSC 5935
