MIL-DTL-39024/15C
TABLE I. Design and identification data. Continued.
Dimension
Insulation
Dash
Terminal
number
style
A (inches 1/)
Material
Color
Number in
accordance with
FED-STD-595/
-45
White
17875
-46
Red
11105
-47
Black
17038
-48
Brown
10075
-49
Green
14110
-50
.180 (4.57)
Orange
12246
-51
Type "B" med short
Blue
15123
-52
.160 (4.06)
Yellow
13655
-53
Gray
16187
-54
ASTM D1710
Purple
27144
-55
Natural
---
-56
White
17875
-57
Red
11105
-58
Black
17038
-59
Brown
10075
-60
.120 (3.05)
Green
14110
-61
Type "B" short
Orange
12246
-62
.100 (2.54)
Blue
15123
-63
Yellow
13655
-64
Gray
16187
-65
Purple
27144
-66
Natural
---
1/ Dimensions are in inches. Metric equivalents are given for information only.
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1 and table I.
Insulation: Material as specified in table I.
Flammability: Dielectric materials shall be self-extinguishing in accordance with ASTM D635.
Test probe: 0.080 ± 0.001 inch in diameter and ½ -inch (min) length. Test probe shall be engaged a
minimum of ½ inch.
Contact current rating: 5 amperes (max).
Contact resistance: A test probe in accordance with MIL-DTL-39024 shall be fully inserted in the
connector. With a current of 5 amperes, potential drop shall be measured between the connector
terminal and the extreme end of the solder cup on the test probe. Measured values shall be within the
limits specified in table II.
