MIL-DTL-55116/7B
Inches
mm
Inches
mm
Inches
mm
.003
.076
.090
2.286
.282
7.163
.005
.127
.092
2.337
.284
7.214
.006
.152
.093
2.362
.483
12.27
.010
.254
.095
2.413
.488
12.40
.020
.508
.100
2.540
.490
12.45
.030
.762
.108
2.743
.494
12.55
.040
1.016
.110
2.794
.496
12.60
.043
1.092
.112
2.845
.555
14.10
.044
1.115
.125
3.175
.559
14.20
.045
1.143
.140
3.556
.597
15.16
.046
1.168
.141
3.581
.603
15.32
.0465
1.181
.149
3.785
.638
16.21
.0475
1.206
.1875
4.762
.642
16.31
.050
1.270
.192
4.877
.717
18.21
.057
1.448
.196
4.978
.721
18.31
.064
1.626
.200
5.080
.770
19.56
.085
2.159
.204
5.182
.775
19.68
.086
2.184
.212
5.385
.826
20.98
.087
2.210
.254
6.452
.836
21.23
.088
2.235
.258
6.553
1.125
28.57
.089
2.261
.280
7.112
1.308
33.22
FIGURE 1. Connector, plug, five pin audio, U-182 type - Continued.
