MIL-DTL-55181/1D
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Unless otherwise specified tolerances are ±.005 inch (0.13 mm) for three place decimals and
±.01 inch (0.3 mm) for two place decimals.
4. Angular tolerances are ±30 minutes unless otherwise specified.
5. See table l for cable size accommodations.
FIGURE 1 Dimensions and configuration - Continued.
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
Contacts: 35 ampere current rating, 12 AWG.
Part or Identifying Number (PIN): M55181/1 - (dash number as specified in table I).
TABLE I. Dash number, cross reference and mating connector.
Cable size accommodation
Mating connector
1/
PIN
Type designator
Type designator 1/
MIN
MAX
PIN
M55181/1-01
MW10F(M)A11
.292 (7.42) .343 (8.71)
M55181/2-01
MW20M(M)A00
M55181/1-02
MW10F(M)A13
.323 (8.20) .406 (10.31)
M55181/2-01
MW20M(M)A00
M55181/1-03
MW10F(M)A17
.448 (11.38) .531 (13.48)
M55181/2-01
MW20M(M)A00
M55181/1-04
MW10F(M)A19
.511 (12.98) .593 (15.06)
M55181/2-01
MW20M(M)A00
M55181/1-05
MW10F(M)A15
.386 (9.80) .468 (11.88)
M55181/2-01
MW20M(M)A00
1/ This type designator shall not be referenced for procurement purposes.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
