MIL-DTL-55181/2D
REQUIREMENTS:
Dimensions and configuration: See figure 1, figure 2, and table I.
Contacts: 35 ampere rating, 12 AWG.
Mating Connectors: M55181/1-01, M55181/1-02, M55181/1-03, and M55181/1-04.
Part or Identifying Number (PIN): M55181/2 (dash number as specified in table I).
Supersession, cross-reference and mating connectors: See table II.
TABLE I. Dash numbers and characteristics.
PIN
M55181/2-01
Without ground washer
M55181/2-01W
With ground washer
TABLE II. Supersession, cross reference and mating connector.
PIN
Old type designator
Old mating type designator
MW10F(M)A11
MW20M(M)A00
M55181/2-01
MW10F(M)A13
MW20M(M)A00
M55181/2-01
MW10F(M)A17
MW20M(M)A00
M55181/2-01
MW10F(M)A19
MW20M(M)A00
M55181/2-01
MW10F(M)A15
MW20M(M)A00
M55181/2-01
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents: In addition to MIL-DTL-55181, this document references the following:
SAE-AMS-2700
4
